Collapsible box
View Catalog
Online Message
Collapsible box
View Catalog
Online Message
|
Dimensions (L×W) |
1200×1000mm, 1100×1100mm, 800×600mm |
Customizable 500×300mm~1500×1200mm |
|
Board Height |
Single Layer 150mm/200mm, Stackable up to 3 Layers |
Total Height = Number of Board Layers × Single Layer Height + Base/Cover Thickness (Approx. 30mm per Layer) |
|
Material |
Base/Cover: HDPE (Impact-Resistant); Board: PP (Lightweight) |
Optional Reinforced PP (with Glass Fiber, Load-Bearing Increased by 20%) |
|
Wall Thickness |
Base 4-5mm, Board 2.5-3mm, Cover 3-4mm |
Heavy-Duty Version Can Be Thickened to Base 6mm, Board 4mm |
|
Static Load-Bearing (Base) |
800-1200kg |
Reinforced Base Can Reach 1500kg |
|
Dynamic Load-Bearing (Handling) |
300-500kg |
Compatible with Forklifts/Pallet Trucks for Stable Handling |
|
Stacking Load-Bearing (Fully Loaded) |
3-4 Layers |
The Bottom Layer Needs to Bear the Total Weight of Upper Layers, Recommended to Be ≤80% of Base Load-Bearing |
|
Temperature Range |
-30℃~60℃ |
High-Temperature Version Can Withstand 80℃ (Custom HDPE Material) |
|
Protective Performance |
Moisture-Proof, Scratch-Resistant, Leak-Proof with Buckle Closure |
Optional Sealing Strip (Waterproof Grade IP54, Suitable for Liquid Cargo) |
|
Volume Ratio After Folding |
1:3-1:5 (Full Box: Empty Box) |
Fewer Layers Result in Smaller Folded Volume |
|
Assembly Time |
1 Person ≤1 Minute per Box |
Buckle Design Requires No Tools |
|
Accessory Options |
Sealing Strip, Label Slot, Anti-Theft Lock Hole, EVA Buffer Liner |
Can Be Added as Needed to Improve Adaptability |
